Duty |
Prime |
|
Rating (kVA) |
100kVA |
|
Engine Model |
mPower41265G |
|
Cylinders |
4 |
|
Voltage |
415V |
|
Governing class |
G2 |
|
Starting system |
12V-DC Elec |
|
Fuel tank capacity |
250L |
|
Genset dimensions |
1425*1230*3500 |
|
Weight |
1650 |
|
Frequency (Hz) |
50 |
|
RPM |
3000 |
|
Make / Series (Engine) |
Mahindra mPower |
|
Power Output# (HP) |
126 |
|
Aspiration |
Turbocharged Aftercooled |
|
Bore x Stroke (mm) |
137*105 |
|
Displacement |
4800 |
|
Fuel consumption @ 75% load (lit/hr) |
17.3 |
|
Fuel consumption @ 100% load (lit/hr) |
23.1 |
|
Total lubrication system capacity (lit) |
13.5 |
|
Lube oil change period |
500 |
|
Radiator coolant capacity |
19L |
|
Make (Alternator) |
CG/LS |
|
Enclosure Type |
IP23 |
|
Voltage regulation |
%1-/+ |
|
Class of insulation |
Class H |
|
Maximum Unbalanced Load across Phases |
25% |
