Duty |
Prime |
|
Rating (kVA) |
250kVA |
|
Rated(KWe) |
200 |
|
Voltage |
415V |
|
No of Phases |
1/3 |
|
Power Factor (lagging) |
0.8 |
|
Current (A) |
3Phase:348 |
|
Frequency (Hz) |
50 |
|
RPM |
1500 |
|
Governing class |
G2 |
|
Starting system |
24V-DC Elec |
|
Fuel tank capacity |
425L |
|
Genset dimensions |
1770*1500*3990 |
|
Weight |
3300 |
|
Make / Series (Engine) |
Mahindra mPower |
|
Engine Model |
mPower63105G |
|
Rated Power (BHP) |
310 |
|
Aspiration |
Turbocharged Aftercooled |
|
Cylinders |
6 |
|
Bore x Stroke (mm) |
146.1*116.6 |
|
Displacement |
9.3 |
|
Fuel consumption @ 75% load (lit/hr) |
41.2 |
|
Fuel consumption @ 100% load (lit/hr) |
54.1 |
|
Lube oil specification |
SAE 15W40CI4+ |
|
Lube Oil Refil Quantity (Lit) |
30 |
|
Lube oil consumption |
1%of Fuel Consumption |
|
Lube oil change period |
500 |
|
Radiator coolant capacity |
31L |
|
Make (Alternator) |
CG, Stamford |
|
Enclosure Type |
IP23 |
|
Voltage regulation |
%1-/+ |
|
Class of insulation |
Class H |
|
Maximum Unbalanced Load across Phases |
25% |
