Duty |
Prime |
|
Rating (kVA) |
320kVA |
|
Rated(KWe) |
256 |
|
Voltage |
415V |
|
Frequency (Hz) |
50 |
|
RPM |
1500 |
|
Starting system |
24V-DC Elec |
|
Fuel tank capacity |
570L |
|
Genset dimensions |
1780*1600*4550 |
|
Weight |
3550 |
|
Make / Series (Engine) |
Mahindra mPower |
|
Engine Model |
mPower63905G |
|
Rated Power (BHP) |
390 |
|
Aspiration |
Turbocharged Aftercooled |
|
Cylinders |
6 |
|
Bore x Stroke (mm) |
146.1*116.6 |
|
Displacement |
9.3 |
|
Fuel consumption @ 75% load (lit/hr) |
51.5 |
|
Fuel consumption @ 100% load (lit/hr) |
67.4 |
|
Lube oil specification |
SAE 15W40CI4+ |
|
Lube Oil Refil Quantity (Lit) |
30 |
|
Lube oil consumption |
1%of Fuel Consumption |
|
Lube oil change period |
500 |
|
Radiator coolant capacity |
45L |
|
Make (Alternator) |
CG, Stamford |
|
Enclosure Type |
IP23 |
|
Voltage regulation |
%1-/+ |
|
Class of insulation |
Class H |
|
Maximum Unbalanced Load across Phases |
25% |
