Duty |
Prime |
|
Rating (kVA) |
625kVA |
|
Rated(KWe) |
500 |
|
Voltage |
415V |
|
Frequency (Hz) |
50 |
|
RPM |
1500 |
|
Starting system |
24V-DC Elec |
|
Fuel tank capacity |
800L |
|
Genset dimensions |
2300*2000*5850 |
|
Weight |
7500 |
|
Make / Series (Engine) |
Perkins |
|
Engine Model |
2806D-E18TAG 1A |
|
Aspiration |
Turbocharged Aftercooled |
|
Cylinders |
6 |
|
Bore x Stroke (mm) |
183*145 |
|
Displacement |
18.1 |
|
Fuel consumption @ 75% load (lit/hr) |
97 |
|
Total lubrication system capacity (lit) |
97 |
|
Lube oil consumption |
1%of Fuel Consumption |
|
Lube oil change period |
500 |
|
Radiator coolant capacity |
55.6 |
|
Make (Alternator) |
CG/LS, Stamford |
|
Enclosure Type |
IP23 |
|
Voltage regulation |
%1-/+ |
|
Class of insulation |
Class H |
|
Maximum Unbalanced Load across Phases |
25% |
